| Nambari ya Sehemu | HSD123KPW2-A10 |
| Chapa | HannStar |
| Ukubwa | 12.3 |
| Maombi | Automotive Display |
| Azimio | 1920×720 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 1100:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 11S4P |
| Kiolesura | LVDS |
| mtengenezaji | HannStar |
| ukubwa wa skrini | 12.3 inch |
| nambari ya pixel | 1920(RGB)×720 167PPI |
| eneo amilifu(mm) | 292.032 × 109.512 (H×V) |
| eneo la bezel(mm) | 294.8 × 112.1 (H×V) |
| mwangaza | 850 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 16.7M 70% NTSC |
| wingi | TBD |
| kiwango cha upya | 60Hz |
| aina ya ishara | LVDS (2 ch, 8-bit) , 50 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| jina la mfano | HSD123KPW2-A10 |
| aina ya skrini | LCM , a-Si TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 308.1 × 130 × 15.6 (H×V×D) |
| matibabu | Glare (Haze 0%) |
| uwiano wa utofautishaji | 1100 : 1 (Typ.) (TM) |
| majibu | 16/14 (Typ.)(Tr/Td) ms |
| hali ya kazi | IPS Pro, Normally Black, Transmissive |
| backlight | 11S4P WLED , 30K hours , No Driver |
| kutumika kwa | Automotive Display |
| skrini ya kugusa | Without |
| AV123Z7M-N11 | BOE | 12.3 | 1920×720 |
| C123HAN01.0 | AUO | 12.3 | 1920×720 |
| C123HAN01.1 | AUO | 12.3 | 1920×720 |
| LA123WF1-SL01 | LG Display | 12.3 | 1920×720 |
| LAM1233548D | JDI | 12.3 | 1920×720 |
| LQ123K1LG03 | SHARP | 12.3 | 1280×480 |
| LQ123K3LG01 | SHARP | 12.3 | 1280×480 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
| TJ123NP01CA | Innolux | 12.3 | 1280×480 |
| TX31D200VM0BAA | KOE | 12.3 | 1280×480 |
