| Nambari ya Sehemu | HSD170PUW1-B00 |
| Chapa | HannStar |
| Ukubwa | 17.0 |
| Maombi | Laptop |
| Azimio | 1920×1200 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | eDP |
| chapa | HannStar |
| mfano | HSD170PUW1-B00 |
| ukubwa wa diagonal | 17.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1920(RGB)×1200 [WUXGA] 133PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 365.184(H)×228.24(V) mm |
| muhtasari dim. | 373.248(H)×241.38(V) ×6(D) mm |
| eneo la bezel | - |
| matibabu | Antiglare |
| mwangaza | 270 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | IPS Pro, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 95% DCI-P3 |
| chanzo cha mwanga | WLED , 15K hours , With LED Driver |
| mtindo wa fomu | - |
| iliyoundwa kwa ajili ya | Laptop |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| aina ya kiolesura | eDP (2 Lanes) , eDP1.3 , 30 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
