| Nambari ya Sehemu | HT07W12-200 |
| Chapa | HYDIS |
| Ukubwa | 7.0 |
| Maombi | CNS |
| Azimio | 480×234 |
| Muundo | LCM |
| Mwangaza | 450 |
| CR | 250:1 |
| Rangi | Full color |
| Mwangaza nyuma | CCFL |
| Kiolesura | Analog |
| chapa ya paneli | BOE HYDIS |
| mfano wa paneli | HT07W12-200 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 480(RGB)×234 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 154.08×87.05 mm |
| muhtasari | 167×102×12.5 mm |
| uso | Antiglare, Hard coating |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 250:1 (Typ.) |
| kuonyesha rangi | Full color |
| wakati wa majibu | 10/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | Analog RGB + Composite Video (NTSC/PAL), 30 pins |
| voltage ya pembejeo | 9.0/5.0/18/-15/-10V (Typ.)(VCOM/VDD/VGH/VGL/VDL) |
| maombi | CNS |
