LM240WU8-SLA2

LM240WU8-SLA2
LM240WU8-SLA2
LM240WU8-SLA2
LM240WU8-SLA2 thumb LM240WU8-SLA2 thumb LM240WU8-SLA2 thumb
Chapa
LG Display
Ukubwa
24.0
Maombi
IA
Azimio
1920×1200
Muundo
LCM
Mwangaza
300
CR
1000:1
Rangi
16.7M
Mwangaza nyuma
WLED
Kiolesura
LVDS
In Stock
576
Vipimo

Nambari ya Sehemu LM240WU8-SLA2
ChapaLG Display
Ukubwa24.0
MaombiIA
Azimio1920×1200
MuundoLCM
Mwangaza300
CR1000:1
Rangi16.7M
Mwangaza nyumaWLED
KiolesuraLVDS
chapa ya paneliLG Display
mfano wa paneliLM240WU8-SLA2
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli24.0 inch
azimio1920(RGB)×1200 , WUXGA
hali ya kuonyeshaUH-IPS, Normally Black, Transmissive
eneo la kazi518.4×324 mm
muhtasari546.4×352×15 mm
usoAntiglare, Hard coating (3H)
mwangaza300 cd/m² (Typ.)
uwiano wa utofautishaji1000:1 (Typ.)
kuonyesha rangi16.7M (6-bit + Hi-FRC), CIE193172%
wakati wa majibu14 (Typ.)(G to G)
angle ya kutazama89/89/89/89 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa4 stringsWLEDWithout Driver
kiolesura cha isharaLVDS (2 ch, 8-bit), 30 pins
voltage ya pembejeo12.0V (Typ.)
maombiIA
Mfano wa Familia
LM240WU2-SLB1 LG Display 24.0 1920×1200
LM240WU3-TLD1 LG Display 24.0 1920×1200
LM240WU4-SLA1 LG Display 24.0 1920×1200
LM240WU5-SLA1 LG Display 24.0 1920×1200
LM240WU6-SDA1 LG Display 24.0 1920×1200
LM240WU7-SLA1 LG Display 24.0 1920×1200
LM240WU7-SLB3 LG Display 24.0 1920×1200
LM240WU8-SLA3 LG Display 24.0 1920×1200
LM240WU8-SLD1 LG Display 24.0 1920×1200
LM240WU8-SLE1 LG Display 24.0 1920×1200
