| Nambari ya Sehemu | LM8V311 |
| Chapa | SHARP |
| Ukubwa | 7.7 |
| Maombi | IA |
| Azimio | 640×480 |
| Muundo | LCM |
| Mwangaza | 55 |
| CR | 30:1 |
| Rangi | Color |
| Mwangaza nyuma | CCFL |
| Kiolesura | Parallel Data |
| chapa ya paneli | SHARP |
| mfano wa paneli | LM8V311 |
| aina ya paneli | CSTN-LCD , LCM |
| saizi ya paneli | 7.7 inch |
| azimio | 640(RGB)×480 , VGA |
| hali ya kuonyesha | STN, Normally Black, Transmissive |
| eneo la kazi | 157.42×118.06 mm |
| muhtasari | 197×142.5 mm |
| uso | |
| mwangaza | 55 cd/m² (Typ.) |
| uwiano wa utofautishaji | 30:1 (Typ.) |
| kuonyesha rangi | Color |
| wakati wa majibu | 270/80 (Typ.)(Tr/Td) |
| angle ya kutazama | 30/30/15/30 (Typ.)(CR≥5)(L/R/U/D) |
| masafa | 75Hz |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel Data (8-bit), 29 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
