| Nambari ya Sehemu | LQ057Q3DC02 |
| Chapa | SHARP |
| Ukubwa | 5.7 |
| Maombi | IA |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 60:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ057Q3DC02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 5.7 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 115.2×86.4 mm |
| muhtasari | 144×104.6×13.5 mm |
| uso | Hard coating (3H), Antireflection |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 60:1 (Min.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 30/50 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/65/40 (Typ.)(CR≥5)(L/R/U/D) |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 33 pins |
| voltage ya pembejeo | 3.3V (Typ.)(VCC) |
| maombi | IA |
| DLC0570BDG-3 | Other | 5.7 | 640×480 |
| LM32004 | SHARP | 5.7 | 320×240 |
| LQ057AC111 | Other | 5.7 | 320×240 |
| LQ057Q3DC02 | SHARP | 5.7 | 320×240 |
| LQ057Q3DC03 | SHARP | 5.7 | 320×240 |
| LQ057Q3DC12 | SHARP | 5.7 | 320×240 |
| LQ057Q3DG02 | SHARP | 5.7 | 320×240 |
| LQ057V3DG01 | SHARP | 5.7 | 640×480 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| LQ057V3LG11 | SHARP | 5.7 | 640×480 |
| AA141TC01 | Mitsubishi | 14.1 | 1280×800 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| KCS057QV1AJ-G23 | Kyocera | 5.7 | 320×240 |
| LB121S03-TL03 | LG Display | 12.1 | 800×600 |
| LM64P83L | SHARP | 9.4 | 640×480 |
| LM8V311 | SHARP | 7.7 | 640×480 |
| MAA121DSK26 | Mitsubishi | 12.1 | 800×600 |
| MC57T04L | Other | 5.7 | 320×240 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| TM057QVHG01 | Tianma | 5.7 | 640×480 |
