| Nambari ya Sehemu | LQ070Y5DG36 |
| Chapa | SHARP |
| Ukubwa | 7.0 |
| Maombi | CNS |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 485 |
| CR | 150:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ070Y5DG36 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800×480(RGB) , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 156.4×82.08 mm |
| muhtasari | 165.2×92.4×11.06 mm |
| uso | |
| mwangaza | 485 cd/m² (Typ.) |
| uwiano wa utofautishaji | 150:1 (Min.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 20/30 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/50/65 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 6S4PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | CNS |
