| Nambari ya Sehemu | LQ070M1SX01 |
| Chapa | SHARP |
| Ukubwa | 7.0 |
| Maombi | PAD |
| Azimio | 1200×1920 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 2000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ070M1SX01 |
| aina ya paneli | IGZO TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 1200(RGB)×1920 , WUXGA |
| hali ya kuonyesha | ASV, Normally Black, Transmissive |
| eneo la kazi | 94.5×151.2 mm |
| muhtasari | 99.7×159.85×1.925 mm |
| uso | Clear, Hard coating |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 2000:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193150% |
| wakati wa majibu | 9/13 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 9S2PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (2 data lanes), 71 pins |
| voltage ya pembejeo | 1.8/3.0/5.5/-5.5V (Typ.)(VDDIO/VDD/VSP/VSN) |
| maombi | PAD |
