| Nambari ya Sehemu | LQ085Y3DG01 |
| Chapa | SHARP |
| Ukubwa | 8.5 |
| Maombi | DPF |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 250:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ085Y3DG01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.5 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 184.8×110.88 mm |
| muhtasari | 222.7×134×12.5 mm |
| uso | Antiglare |
| mwangaza | 200 cd/m² (Min.) |
| uwiano wa utofautishaji | 250:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 30/50 (Typ.)(Tr/Td) |
| angle ya kutazama | 55/55/60/40 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 1 pcsCCFLWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.)(VCC) |
| maombi | DPF |
| AT070TN90 V.1 | Innolux | 7.0 | 800×480 |
| AT080TN03 V.7 | Innolux | 8.0 | 800×480 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| AT102TN03 V.9 | Innolux | 10.2 | 800×480 |
| EK08009-70235 | Other | 8.0 | 800×600 |
| HSD100IFW1-A00 | HannStar | 10.1 | 1024×600 |
| HSD101PFW4-A00 | HannStar | 10.1 | 1024×600 |
| LB070WV1-TD17 | LG Display | 7.0 | 800×480 |
| LD050WQ1-TD02 | LG Display | 5.0 | 480×272 |
| PA079DS1T2 | E Ink | 7.9 | 480×234 |
