| Nambari ya Sehemu | AT090TN12 V.3 |
| Chapa | Innolux |
| Ukubwa | 9.0 |
| Maombi | DPF |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 500:1 |
| Rangi | 262K/16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | INNOLUX |
| mfano wa paneli | AT090TN12 V.3 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 198×111.696 mm |
| muhtasari | 211.1×126.5 mm |
| uso | Antiglare |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 262K/16.2M (6-bit / 6-bit + Dithering), CIE193150% |
| wakati wa majibu | 10/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 3S11PWLEDWithout Driver |
| kiolesura cha ishara | TTL (1 ch, 6/8-bit), 50 pins |
| voltage ya pembejeo | 3.3/10.4/17.0/-5.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| maombi | DPF |
| AA090AA01 | Mitsubishi | 9.0 | 960×540 |
| AA090MC01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN10 | Innolux | 9.0 | 800×480 |
| AT090TN12 V.3 | Innolux | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| CLAA090LC41CW | CPT | 9.0 | 800×480 |
| CLAA090NA02CW | CPT | 9.0 | 1024×600 |
| LTL090CL01-002 | Samsung | 9.0 | 1920×1280 |
| ZE090NA-01B | Innolux | 9.0 | 1280×800 |
| A070FW03 VB | AUO | 7.0 | 480×234 |
| A080SN01 V8 | AUO | 8.0 | 800×600 |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| AT056TN52 V.3 | Innolux | 5.6 | 640×480 |
| AT080TN03 V.1 | Innolux | 8.0 | 800×480 |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| CLAA101ND02CW | CPT | 10.1 | 1024×600 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| HSD100IFW3-A00 | HannStar | 10.1 | 1024×600 |
| TM102WV-A02-03 | SANYO | 10.2 | 800×480 |
