| Nambari ya Sehemu | AT102TN03 V.9 |
| Chapa | Innolux |
| Ukubwa | 10.2 |
| Maombi | DPF |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 300:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | INNOLUX |
| mfano wa paneli | AT102TN03 V.9 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.2 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 222×132.48 mm |
| muhtasari | 235×145.8×6.3 mm |
| uso | Antiglare |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193150% |
| wakati wa majibu | 15/20 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/45/65 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S10PWLEDWithout Driver |
| kiolesura cha ishara | TTL (1 ch, 6-bit), 60 pins |
| voltage ya pembejeo | 3.3/9.2/16/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| maombi | DPF |
