| Nambari ya Sehemu | LQ092B5DW02 |
| Chapa | SHARP |
| Ukubwa | 9.2 |
| Maombi | IA |
| Azimio | 960×160 |
| Muundo | LCM |
| Mwangaza | 1050 |
| CR | 1000:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | SHARP |
| mfano wa paneli | LQ092B5DW02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 9.2 inch |
| azimio | 960(RGB)×160 |
| hali ya kuonyesha | ASV, Normally Black, Transmissive |
| eneo la kazi | 230.4×38.4 mm |
| muhtasari | 242×52.83×10.8 mm |
| uso | Antiglare |
| mwangaza | 1050 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 8/6 (Typ.)(Tr/Td) |
| angle ya kutazama | |
| masafa | 60Hz |
| aina ya taa | 6S4PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit), 50 pins |
| voltage ya pembejeo | 3.3/13.4/25.0/-8.0V (Typ.)(VSHD/VSHA/VGH/VGL) |
| maombi | IA |
