| Nambari ya Sehemu | NL10276BC30-18L |
| Chapa | NLT |
| Ukubwa | 15.0 |
| Maombi | IA |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 270 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | NEC |
| mfano wa paneli | NL10276BC30-18L |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 15.0 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 304.128×228.096 mm |
| muhtasari | 326.5×253.5×17 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 270 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193140% |
| wakati wa majibu | 4/14 (Typ.)(Tr/Td) |
| angle ya kutazama | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| rohs: | |
| maombi | IA |
| NL10276AC28-05R | NLT | 14.1 | 1024×768 |
| NL10276AC30-04R | NLT | 15.0 | 1024×768 |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| NL10276BC30-15 | NLT | 15.0 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18C | NLT | 15.0 | 1024×768 |
| NL10276BC30-38B | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| AA121SL07 | Mitsubishi | 12.1 | 800×600 |
| AM-1024768MTMQW-00H | AMPIRE | 10.4 | 1024×768 |
| HV121X02-100 | HYDIS | 12.1 | 1024×768 |
| KCB6448BSTT-X11 | Kyocera | 10.4 | 640×480 |
| KCG057QV1DB-G77 | Kyocera | 5.7 | 320×240 |
| KCS057QV1AJ-G20 | Kyocera | 5.7 | 320×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| LQ10D41 | SHARP | 10.4 | 640×480 |
| LQ121S1LG81 | SHARP | 12.1 | 800×600 |
| OEL9M0073-R-E | Other | 1.0 | 128×64 |
