| Nambari ya Sehemu | NL10276BC30-39 |
| Chapa | NLT |
| Ukubwa | 15.0 |
| Maombi | IA |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 270 |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | NEC |
| mfano wa paneli | NL10276BC30-39 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 15.0 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | UA-SFT, Normally Black, Transmissive |
| eneo la kazi | 304.128×228.096 mm |
| muhtasari | 326.5×253.5×12.2 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 270 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193172% |
| wakati wa majibu | 14/11 (Typ.)(Tr/Td) |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 6 stringsWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
