| Nambari ya Sehemu | LTL089CL02-001 |
| Chapa | Samsung |
| Ukubwa | 8.9 |
| Maombi | PAD |
| Azimio | 1920×1200 |
| Muundo | LCM |
| Mwangaza | 450 |
| CR | 900:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTL089CL02-001 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.9 inch |
| azimio | 1920(RGB)×1200 , WUXGA |
| hali ya kuonyesha | PLS, Normally Black, Transmissive |
| eneo la kazi | 191.52×119.7 mm |
| muhtasari | 203.5×135.9×5.2 mm |
| uso | Glare (Haze 0%), Hard coating (2H) |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 7S5PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 45 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
| B080EAN01.1 | AUO | 8.0 | 800×1280 |
| B101EAN01.6 | AUO | 10.1 | 1280×800 |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| HSD100PXN1-A00 | HannStar | 10.0 | 1024×768 |
| HV121X03-100 | HYDIS | 12.1 | 1024×768 |
| LD070WU1-SM01 | LG Display | 7.0 | 1200×1920 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| N070ICE-GB1 | Innolux | 7.0 | 800×1280 |
