| Nambari ya Sehemu | LTL106AL01-002 |
| Chapa | Samsung |
| Ukubwa | 10.6 |
| Maombi | PAD |
| Azimio | 1366×768 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | SAMSUNG |
| mfano wa paneli | LTL106AL01-002 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.6 inch |
| azimio | 1366(RGB)×768 , WXGA |
| hali ya kuonyesha | PLS, Normally Black, Transmissive |
| eneo la kazi | 234.72×132.03 mm |
| muhtasari | 246.52×149.02×5.2 mm |
| uso | Glare (Haze 0%), Hard coating (2H) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193150% |
| wakati wa majibu | 16 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDEmbedded (LED Driver) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
| BF097XN | Innolux | 9.7 | 1024×768 |
| BP070WX6-400 | BOE | 7.0 | 800×1280 |
| CLAA080WQ05 | CPT | 8.0 | 800×1280 |
| HT12X21-220 | HYDIS | 12.1 | 1024×768 |
| HV070WX2-1E0 | HYDIS | 7.0 | 800×1280 |
| HV101WU1-1E3 | HYDIS | 10.1 | 1920×1200 |
| HV121WX5-114 | HYDIS | 12.1 | 1280×800 |
| LTL089CL02-001 | Samsung | 8.9 | 1920×1200 |
| P101KDA-AP1 | Innolux | 10.1 | 1200×1920 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
