| Nambari ya Sehemu | LW850AT9301 |
| Chapa | Innolux |
| Ukubwa | 8.5 |
| Maombi | DPF |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 270 |
| CR | 300:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | CHIMEI INNOLUX |
| mfano wa paneli | LW850AT9301 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.5 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 184.8×110.88 mm |
| muhtasari | 206.1×124.48×8.5 mm |
| uso | Antiglare (Haze 25%) |
| mwangaza | 270 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + FRC), CIE193150% |
| wakati wa majibu | 15/35 (Typ.)(Tr/Td) |
| angle ya kutazama | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 3.3V (Typ.)(VCC) |
| maombi | DPF |
