| Nambari ya Sehemu | EJ080NA-04C |
| Chapa | Innolux |
| Ukubwa | 8.0 |
| Maombi | DPF |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 700:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | CHIMEI INNOLUX |
| mfano wa paneli | EJ080NA-04C |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.0 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 162.048×121.536 mm |
| muhtasari | 183×141 mm |
| uso | Hard coating |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 6/14 (Typ.)(Tr/Td) |
| angle ya kutazama | 75/75/75/75 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 40 pins |
| voltage ya pembejeo | 3.3/11.5/22/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| maombi | DPF |
