| Nambari ya Sehemu | M220Z1-L03 |
| Chapa | Innolux |
| Ukubwa | 22.0 |
| Maombi | DMPC |
| Azimio | 1680×1050 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | CMO |
| mfano wa paneli | M220Z1-L03 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 22.0 inch |
| azimio | 1680(RGB)×1050 , WSXGA+ |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 473.76×296.1 mm |
| muhtasari | 493.7×320.1 mm |
| uso | Antiglare (Haze 25%), Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (6-bit + Hi-FRC), CIE193172% |
| wakati wa majibu | 1.3/3.7 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4 pcsCCFLWithout Driver |
| kiolesura cha ishara | LVDS (2 ch, 8-bit), 30 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
| HT15X15-D01 | HYDIS | 15.0 | 1024×768 |
| LM150X06-A4C4 | LG Display | 15.0 | 1024×768 |
| LM170E03-TLJ6 | LG Display | 17.0 | 1280×1024 |
| LM185WH1-TLD1 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLA1 | LG Display | 18.5 | 1366×768 |
| LM201W01-B6K1 | LG Display | 20.1 | 1680×1050 |
| M190ETN01.0 | AUO | 19.0 | 1280×1024 |
| M240UW04 V1 | AUO | 24.0 | 1920×1200 |
| M270DTN01.3 | AUO | 27.0 | 2560×1440 |
| MV236WHM-N10 | BOE | 23.6 | 1366×768 |
