MT190AW02 V.W

MT190AW02 V.W
MT190AW02 V.W
MT190AW02 V.W
MT190AW02 V.W thumb MT190AW02 V.W thumb MT190AW02 V.W thumb
Chapa
Innolux
Ukubwa
19.0
Maombi
DMPC
Azimio
1440×900
Muundo
LCM
Mwangaza
250
CR
1000:1
Rangi
16.7M
Mwangaza nyuma
WLED
Kiolesura
LVDS
In Stock
225
Vipimo

Nambari ya Sehemu MT190AW02 V.W
ChapaInnolux
Ukubwa19.0
MaombiDMPC
Azimio1440×900
MuundoLCM
Mwangaza250
CR1000:1
Rangi16.7M
Mwangaza nyumaWLED
KiolesuraLVDS
chapa ya paneliINNOLUX
mfano wa paneliMT190AW02 V.W
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli19.0 inch
azimio1440(RGB)×900 , WXGA+
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi408.24×255.15 mm
muhtasari428×278 mm
usoAntiglare (Haze 25%), Hard coating (3H)
mwangaza250 cd/m² (Typ.)
uwiano wa utofautishaji1000:1 (Typ.)
kuonyesha rangi16.7M (6-bit + Hi-FRC), CIE193168%
wakati wa majibu1.5/3.5 (Typ.)(Tr/Td)
angle ya kutazama85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa5 stringsWLEDWithout Driver
kiolesura cha isharaLVDS (2 ch, 8-bit), 30 pins
voltage ya pembejeo5.0V (Typ.)
maombiDMPC
Mfano wa Familia
HSD190MEN4-A03 HannStar 19.0 1280×1024
MT190AW01 V.5 Innolux 19.0 1440×900
MT190AW01 V.7 Innolux 19.0 1440×900
MT190AW01 V.C Innolux 19.0 1440×900
MT190AW02 V.0 Innolux 19.0 1440×900
MT190AW02 V.4 Innolux 19.0 1440×900
MT190AW02 V.A Innolux 19.0 1440×900
MT190AW02 V.V Innolux 19.0 1440×900
MT190AW02 V.W Innolux 19.0 1440×900
MT190AW02 V.Y Innolux 19.0 1440×900
