MT190AW02 V.Y

MT190AW02 V.Y
MT190AW02 V.Y
MT190AW02 V.Y
MT190AW02 V.Y thumb MT190AW02 V.Y thumb MT190AW02 V.Y thumb
Chapa
Innolux
Ukubwa
19.0
Maombi
DMPC
Azimio
1440×900
Muundo
LCM
Mwangaza
300
CR
1000:1
Rangi
16.7M
Mwangaza nyuma
CCFL
Kiolesura
LVDS
In Stock
40
Vipimo

Nambari ya Sehemu MT190AW02 V.Y
ChapaInnolux
Ukubwa19.0
MaombiDMPC
Azimio1440×900
MuundoLCM
Mwangaza300
CR1000:1
Rangi16.7M
Mwangaza nyumaCCFL
KiolesuraLVDS
chapa ya paneliINNOLUX
mfano wa paneliMT190AW02 V.Y
aina ya paneli a-Si TFT-LCD , LCM
saizi ya paneli19.0 inch
azimio1440(RGB)×900 , WXGA+
hali ya kuonyeshaTN, Normally White, Transmissive
eneo la kazi408.24×255.15 mm
muhtasari428×278×16.5 mm
usoAntiglare (Haze 25%), Hard coating (3H)
mwangaza300 cd/m² (Typ.)
uwiano wa utofautishaji1000:1 (Typ.)
kuonyesha rangi16.7M (6-bit + Hi-FRC), CIE193172%
wakati wa majibu1.5/3.5 (Typ.)(Tr/Td)
angle ya kutazama85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
masafa60Hz
aina ya taa4 pcsCCFLWithout Driver
kiolesura cha isharaLVDS (2 ch, 8-bit), 30 pins
voltage ya pembejeo5.0V (Typ.)
maombiDMPC
Mfano wa Familia
LM190E08-TLL1 LG Display 19.0 1280×1024
MT190AW01 V.5 Innolux 19.0 1440×900
MT190AW01 V.7 Innolux 19.0 1440×900
MT190AW01 V.C Innolux 19.0 1440×900
MT190AW02 V.0 Innolux 19.0 1440×900
MT190AW02 V.4 Innolux 19.0 1440×900
MT190AW02 V.A Innolux 19.0 1440×900
MT190AW02 V.V Innolux 19.0 1440×900
MT190AW02 V.W Innolux 19.0 1440×900
MT190AW02 V.Y Innolux 19.0 1440×900
