| Nambari ya Sehemu | NL10276AC30-04R |
| Chapa | NLT |
| Ukubwa | 15.0 |
| Maombi | DMPC |
| Azimio | 1024×768 |
| Muundo | LCM |
| Mwangaza | 200 |
| CR | 200:1 |
| Rangi | 262K |
| Mwangaza nyuma | CCFL |
| Kiolesura | LVDS |
| chapa ya paneli | NEC |
| mfano wa paneli | NL10276AC30-04R |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 15.0 inch |
| azimio | 1024(RGB)×768 , XGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 304.128×228.096 mm |
| muhtasari | 350×265×20.5 mm |
| uso | Antireflection |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 200:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit), CIE193140% |
| wakati wa majibu | 15/40 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 2 pcsCCFLEmbedded (Inverter) |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 5.0V (Typ.) |
| maombi | DMPC |
