| Nambari ya Sehemu | PM070WL3 |
| Chapa | E Ink |
| Ukubwa | 7.0 |
| Maombi | IA |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 400:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | PVI |
| mfano wa paneli | PM070WL3 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 152.4×91.44 mm |
| muhtasari | 166.3×105.3×11 mm |
| uso | Antiglare |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 15/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 3S11PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
| G057QTN01.1 | AUO | 5.7 | 320×240 |
| G150XG03 V1 | AUO | 15.0 | 1024×768 |
| HTW-G320240B2 | Other | 5.7 | 320×240 |
| LM081HB1T01 | SHARP | 8.1 | 640×240 |
| LQ057V3DG02 | SHARP | 5.7 | 640×480 |
| LQ10D368 | SHARP | 10.4 | 640×480 |
| M150GNN2 R1 | IVO | 15.0 | 1024×768 |
| MD286TT00-C1 | ORTUSTECH | 10.4 | 640×480 |
| TCG057QVLHA-G00 | Kyocera | 5.7 | 320×240 |
| TX38D18VM2BAA REV.B | KOE | 15.0 | 1024×768 |
