| Nambari ya Sehemu | PM070WL4 |
| Chapa | E Ink |
| Ukubwa | 7.0 |
| Maombi | IA |
| Azimio | 800×480 |
| Muundo | LCM |
| Mwangaza | 330 |
| CR | 400:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | PVI |
| mfano wa paneli | PM070WL4 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×480 , WVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 152.4×91.44 mm |
| muhtasari | 166.3×105.3×12.75 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 330 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | 262K (6-bit) |
| wakati wa majibu | 15/25 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/55 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 3S11PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6-bit), 20 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | IA |
