| Nambari ya Sehemu | R156B48-167-0101 |
| Chapa | No Brand |
| Ukubwa | 15.6 |
| Maombi | Laptop |
| Azimio | 1366×768 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | 8S6P |
| Kiolesura | LVDS |
| chapa ya paneli | No Brand |
| mfano wa paneli | R156B48-167-0101 1 Compatible |
| saizi ya paneli | 15.6" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1366(RGB)×768, WXGA, 100PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 344.232(W)×193.536(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 359.3(W)×209.5(H) ×5.5(D) mm |
| uso | Glare (Haze 0%) |
| mwangaza | 200 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) (TM) |
| angle ya kutazama | 45/45/20/40 (Typ.)(CR≥10) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| mwonekano bora zaidi | - |
| wakati wa majibu | 12 (Typ.)(Tr+Td) |
| kuonyesha rangi | 262K 45% NTSC |
| aina ya taa | 8S6P WLED , 15K hours , With LED Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| mtindo wa sura | Wedge (PCBA Bent, T≥5.2mm) |
| maombi | Laptop |
| kiolesura cha ishara | LVDS (1 ch, 6-bit) , 40 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| B156HTN04.0 | AUO | 15.6 | 1920×1080 |
| BT156GW01 V.4 | Innolux | 15.6 | 1366×768 |
| LTN156AT01-B01 | Samsung | 15.6 | 1366×768 |
| LTN156AT01-B02 | Samsung | 15.6 | 1366×768 |
| LTN156AT05-H01 | Samsung | 15.6 | 1366×768 |
| LTN156AT17-D01 | Samsung | 15.6 | 1366×768 |
| N156B3-L02 | Innolux | 15.6 | 1366×768 |
| N156BGE-E42 | Innolux | 15.6 | 1366×768 |
| N156O6-L02 | Innolux | 15.6 | 1600×900 |
| TMS156WX1-02TC | Tianma | 15.6 | 1366×768 |
