| Nambari ya Sehemu | STCG057QVLAD-G00 |
| Chapa | Kyocera |
| Ukubwa | 5.7 |
| Maombi | Industrial |
| Azimio | 320×240 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| mtengenezaji | Kyocera |
| jina la mfano | STCG057QVLAD-G00 |
| ukubwa wa skrini | 5.7 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 320(RGB)×240 (QVGA) 70PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 115.2 × 86.4 (H×V) |
| muhtasari(mm) | - |
| eneo la bezel(mm) | - |
| matibabu | Glare (Haze 0%) |
| mwangaza | - |
| uwiano wa utofautishaji | 500 : 1 (Typ.) (TM) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥5) |
| majibu | 10/25 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | - |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 262K |
| backlight | WLED |
| wingi | - |
| kutumika kwa | Industrial |
| kiwango cha upya | - |
| skrini ya kugusa | 4-wire Resistive Touch |
| aina ya ishara | Parallel RGB (1 ch, 6-bit) |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
