| Nambari ya Sehemu | TCG085WVLCF-G00 |
| Chapa | Kyocera |
| Ukubwa | 8.5 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | LCM , a-Si TFT-LCD |
| Mwangaza | |
| CR | 500:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| mtengenezaji | Kyocera |
| jina la mfano | TCG085WVLCF-G00 |
| ukubwa wa skrini | 8.5 inch |
| aina ya skrini | LCM , a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×480 (WVGA) 109PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 184.8 × 110.88 (H×V) |
| muhtasari(mm) | 210 × 134 × 11.1 (H×V×D) |
| eneo la bezel(mm) | - |
| matibabu | Antiglare |
| mwangaza | 320 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500 : 1 (Typ.) (TM) |
| angle ya kutazama | 60/60/60/45 (Typ.)(CR≥10) |
| majibu | 15/35 (Typ.)(Tr/Td) ms |
| mtazamo mzuri | - |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 262K 49% NTSC |
| backlight | WLED , 50K hours , No Driver |
| wingi | TBD |
| kutumika kwa | Industrial |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | 4-wire Resistive Touch, G/G |
| aina ya ishara | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| A085FW01 V5 | AUO | 8.5 | 480×234 |
| G085VW01 V0 | AUO | 8.5 | 800×480 |
| G085VW01 V1 | AUO | 8.5 | 800×480 |
| G085VW01 V3 | AUO | 8.5 | 800×480 |
| KMT085WV | Samsung | 8.5 | 800×480 |
| LM085YB1T01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG01 | SHARP | 8.5 | 800×480 |
| LQ085Y3DG18 | SHARP | 8.5 | 800×480 |
| LT085AC18N00 | TOSHIBA | 8.5 | 800×480 |
| LW850AT9301 | Innolux | 8.5 | 800×480 |
