| Nambari ya Sehemu | TD035STED4 |
| Chapa | TPO |
| Ukubwa | 3.5 |
| Maombi | PDA |
| Azimio | 240×320 |
| Muundo | LCM |
| Mwangaza | 115 |
| CR | 100:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | Toppoly |
| mfano wa paneli | TD035STED4 |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 240(RGB)×320 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transflective |
| eneo la kazi | 53.28×71.04 mm |
| muhtasari | 64.3×87.1×4.8 mm |
| uso | |
| mwangaza | 115 cd/m² (Typ.) |
| uwiano wa utofautishaji | 100:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| kuonyesha rangi | 262K (6-bit), CIE193136% |
| wakati wa majibu | 35 (Typ.)(Tr+Td) |
| angle ya kutazama | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 4S1PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) + SPI, 61 pins |
| voltage ya pembejeo | 2.8/5.0/10/-5.5V (Typ.)(VDD/AVDD/VGH/WEE) |
| maombi | PDA |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| NL2432HC22-22B | NLT | 3.5 | 240×320 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-40J | NLT | 3.5 | 240×320 |
| NL2432HC22-41B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TD035STED7 | TPO | 3.5 | 240×320 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
