| Nambari ya Sehemu | TD035STED7 |
| Chapa | TPO |
| Ukubwa | 3.5 |
| Maombi | PDA |
| Azimio | 240×320 |
| Muundo | LCM |
| Mwangaza | 115 |
| CR | 100:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | TPO |
| mfano wa paneli | TD035STED7 |
| aina ya paneli | LTPS TFT-LCD , LCM |
| saizi ya paneli | 3.5 inch |
| azimio | 240(RGB)×320 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transflective |
| eneo la kazi | 53.28×71.04 mm |
| muhtasari | 64×85×5.5 mm |
| uso | |
| mwangaza | 115 cd/m² (Typ.) |
| uwiano wa utofautishaji | 100:1 (Typ.)(Transmissive)15:1 (Typ.)(Reflective) |
| kuonyesha rangi | 262K (6-bit), CIE193136% |
| wakati wa majibu | 35 (Typ.)(Tr+Td) |
| angle ya kutazama | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 6S1PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 6-bit) + SPI, 60 pins |
| voltage ya pembejeo | 2.8/2.8/5/10/-5.0V (Typ.)(VDD1/VDD2/AVDD/VGH/VVEE) |
| maombi | PDA |
| DLC0350TZG | Other | 3.5 | 240×320 |
| GPM782A0 | Giantplus | 3.5 | 320×240 |
| NL2432HC22-32B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| PD035OX1 | E Ink | 3.5 | 320×234 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| TD035STEB1 | TPO | 3.5 | 240×320 |
| TD035STEB2 | TPO | 3.5 | 240×320 |
| TD035STED4 | TPO | 3.5 | 240×320 |
| TD035STED7 | TPO | 3.5 | 240×320 |
| LQ035Q7DH02 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LTM035A776B | TOSHIBA | 3.5 | 240×320 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| NL2432HC22-23B | NLT | 3.5 | 240×320 |
| NL2432HC22-40J | NLT | 3.5 | 240×320 |
| NL2432HC22-50B | NLT | 3.5 | 240×320 |
| TD026TTEA1 | TPO | 2.6 | 480×640 |
| TM038QV-67A02A | SANYO | 3.8 | 320×240 |
| TX09D23VM1CAA | KOE | 3.5 | 240×320 |
