| Nambari ya Sehemu | TM027CDH04 |
| Chapa | Tianma |
| Ukubwa | 2.7 |
| Maombi | DSC |
| Azimio | 320×240 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 350:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Serial RGB |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM027CDH04 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 2.7 inch |
| azimio | 320(RGB)×240 , QVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 54×40.5 mm |
| muhtasari | 63.5×46.6×2.8 mm |
| uso | Clear, Hard coating (3H) |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 350:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193140% |
| wakati wa majibu | 25/40 (Typ./Max.)(Tr+Td) |
| angle ya kutazama | 50/50/25/55 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 2S1PWLEDWithout Driver |
| kiolesura cha ishara | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | DSC |
