| Nambari ya Sehemu | TM047NBH01 |
| Chapa | Tianma |
| Ukubwa | 4.7 |
| Maombi | PND |
| Azimio | 480×272 |
| Muundo | LCM |
| Mwangaza | 280 |
| CR | 500:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | TTL |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM047NBH01 1 Compatible model |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 4.7 inch |
| azimio | 480(RGB)×272 , WQVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 103.68×58.752 mm |
| muhtasari | 114.3×72.5 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 280 cd/m² (Typ.) |
| uwiano wa utofautishaji | 500:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193150% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 5S2PWLEDWithout Driver |
| kiolesura cha ishara | Parallel RGB (1 ch, 8-bit) + SPI, 45 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PND |
| DMF5003NF-FW | Kyocera | 4.7 | 160×128 |
| LH467WX1-SD01 | LG Display | 4.7 | 768×1280 |
| LM32010P | SHARP | 4.7 | 320×240 |
| LQ047K3SX06 | SHARP | 4.7 | 720×1280 |
| LQ047K3SX08 | SHARP | 4.7 | 720×1280 |
| PG320240C | Other | 4.7 | 320×240 |
| TM047NBH01 | Tianma | 4.7 | 480×272 |
| TM047NBH03 | Tianma | 4.7 | 480×272 |
| TM047NDH01 | Tianma | 4.7 | 480×272 |
| TM047XDZP02 | Tianma | 4.7 | 540×960 |
| AT050TN34 | Innolux | 5.0 | 480×272 |
| CLAA048LA0BCW | CPT | 4.8 | 800×480 |
| DLC0500HZG-8 | Other | 5.0 | 800×480 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| LB050WQ2-TD03 | LG Display | 5.0 | 480×272 |
| LMS430HF20 | Samsung | 4.3 | 480×272 |
| LMS430HF41-004 | Samsung | 4.3 | 480×272 |
| LQ043T3DG01 | SHARP | 4.3 | 480×272 |
| TM047NDH01 | Tianma | 4.7 | 480×272 |
| TMT035DNAFWU19 | Tianma | 3.5 | 320×240 |
