| Nambari ya Sehemu | TM047XDZP02 |
| Chapa | Tianma |
| Ukubwa | 4.7 |
| Maombi | MPH |
| Azimio | 540×960 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM047XDZP02 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 4.7 inch |
| azimio | 540(RGB)×960 , qHD |
| hali ya kuonyesha | SFT, Normally Black, Transmissive |
| eneo la kazi | 58.32×103.68 mm |
| muhtasari | 62.72×113.53×1.78 mm |
| uso | |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193170% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 5S2PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (2 data lanes), 24 pins |
| voltage ya pembejeo | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| maombi | MPH |
