| Nambari ya Sehemu | TM070RDHG25 |
| Chapa | TIANMA |
| Ukubwa | 7.0 |
| Maombi | Industrial |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 262K |
| Mwangaza nyuma | 3S8P |
| Kiolesura | |
| chapa ya paneli | TIANMA |
| saizi ya paneli | 7.0" |
| azimio | 800(RGB)×480, WVGA, 134PPI |
| eneo la maonyesho | 154.08(W)×85.92(H) mm |
| saizi ya muhtasari | 164.9(W)×100(H) ×8.1(D) mm |
| mwangaza | 450 cd/m² (Typ.) |
| angle ya kutazama | 80/80/60/80 (Typ.)(CR≥10) |
| mwonekano bora zaidi | 6 o'clock |
| kuonyesha rangi | 262K 50% NTSC |
| masafa | 60Hz |
| uzito | TBD |
| mfano wa paneli | TM070RDHG25 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 157.08(W)×89.39(H) mm |
| uso | Antiglare |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 15 (Typ.)(Tr+Td) |
| aina ya taa | 3S8P WLED , 20K hours , Without Driver |
| skrini ya kugusa | Without |
| maombi | Industrial |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
