| Nambari ya Sehemu | TM070RDHG34 |
| Chapa | TIANMA |
| Ukubwa | 7.0 |
| Maombi | Industrial Outdoor H |
| Azimio | 800×480 |
| Muundo | LCM, a-Si TFT-LCD |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 3S8P |
| Kiolesura | |
| mtengenezaji | TIANMA |
| jina la mfano | TM070RDHG34 |
| ukubwa wa skrini | 7.0 inch |
| aina ya skrini | LCM, a-Si TFT-LCD |
| nambari ya pixel | 800(RGB)×480 (WVGA) 134PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 154.08 × 85.92 (H×V) |
| muhtasari(mm) | 164.9 × 100 × 6 (H×V×D) |
| eneo la bezel(mm) | 157.08 × 89.39 (H×V) |
| matibabu | Antiglare |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800 : 1 (Typ.) (TM) |
| angle ya kutazama | 70/70/60/70 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | 6 o'clock |
| hali ya kazi | TN, Normally White, Transmissive |
| kina cha rangi | 16.7M 50% NTSC |
| backlight | 3S8P WLED , 50K hours , No Driver |
| wingi | TBD |
| kutumika kwa | Industrial Outdoor High Brightness Automotive Display |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
