| Nambari ya Sehemu | TM080RDHP07 |
| Chapa | TIANMA |
| Ukubwa | 8.0 |
| Maombi | Automotive Display |
| Azimio | 800×480 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| chapa | TIANMA |
| ukubwa wa diagonal | 8.0 inch |
| muundo wa pixel | 800(RGB)×480 [WVGA] 116PPI |
| eneo la kazi | 174(H)×104.4(V) mm |
| eneo la bezel | 177(H)×107.4(V) mm |
| mwangaza | 600 cd/m² (Typ.) |
| tazama mwelekeo | Symmetry |
| angle ya kutazama | 88/88/88/88 (Typ.)(CR≥10) |
| rangi ya msaada | 16.7M 71% NTSC |
| uzito | TBD |
| kiwango cha fremu | 60Hz |
| aina ya kiolesura | Parallel RGB (1 ch, 8-bit) , 60 pins FPC |
| usambazaji wa nguvu | 3.3/6.0/-6.0/17/-8V (Typ.)(VCC/VDDP/VDDN/VGH/VGL) |
| mazingira | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 3.0G (29.4 m/s²) |
| mfano | TM080RDHP07 |
| aina | a-Si TFT-LCD , LCM |
| usanidi | RGB Vertical Stripe |
| muhtasari dim. | 190.4(H)×120.7(V) ×16.1(D) mm |
| matibabu | Antiglare |
| uwiano wa utofautishaji | 1000:1 (Typ.) (TM) |
| wakati wa majibu | 50 (Max.)(Tr+Td) |
| hali ya uendeshaji | SFT, Normally Black, Transmissive |
| chanzo cha mwanga | WLED [8S2P] , 20K hours , W/O Driver |
| iliyoundwa kwa ajili ya | Automotive Display |
| jopo la kugusa | Without |
