| Nambari ya Sehemu | TM080VDSP01 |
| Chapa | Tianma |
| Ukubwa | 8.0 |
| Maombi | PAD |
| Azimio | 1200×1920 |
| Muundo | LCM |
| Mwangaza | 390 |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | TIANMA |
| mfano wa paneli | TM080VDSP01 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 8.0 inch |
| azimio | 1200(RGB)×1920 , WUXGA |
| hali ya kuonyesha | SFT, Normally Black, Transmissive |
| eneo la kazi | 107.64×172.224 mm |
| muhtasari | 114.6×184.1×2.3 mm |
| uso | |
| mwangaza | 390 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193160% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 7S3PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 31 pins |
| voltage ya pembejeo | 3.3/10.0/18.0/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| maombi | PAD |
