| Nambari ya Sehemu | TM101DDHG04 |
| Chapa | TIANMA |
| Ukubwa | 10.1 |
| Maombi | Industrial |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | 10S3P |
| Kiolesura | |
| chapa ya paneli | TIANMA |
| saizi ya paneli | 10.1" |
| azimio | 1024(RGB)×600, WSVGA, 117PPI |
| eneo la maonyesho | 222.72(W)×125.28(H) mm |
| saizi ya muhtasari | 233.1(W)×137.1(H) ×3.3(D) mm |
| mwangaza | 300 cd/m² (Typ.) |
| angle ya kutazama | 80/80/75/80 (Typ.)(CR≥10) |
| mwonekano bora zaidi | 12 o'clock |
| kuonyesha rangi | 262K/16.7M 47% NTSC |
| masafa | 60Hz |
| uzito | 210/220g (Typ./Max.) |
| mfano wa paneli | TM101DDHG04 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 225.72(W)×128.28(H) mm |
| uso | Antiglare, Hard coating (3H) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| wakati wa majibu | 7/9 (Typ.)(Tr/Td) |
| aina ya taa | 10S3P WLED , 15K hours , Without Driver |
| skrini ya kugusa | Without |
| maombi | Industrial |
| AM-1280800N2TZQW-00H | AMPIRE | 10.1 | 1280×800 |
| B101EAN02.2 | AUO | 10.1 | 800×1280 |
| BP101WX1-210 | BOE | 10.1 | 1280×800 |
| CLAA101FP01 XG | CPT | 10.1 | 1920×1200 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| LTL101AL06-W14 | Samsung | 10.1 | 1280×800 |
| N101LGE-L41 | Innolux | 10.1 | 1024×600 |
| TM101DDHG01 | Tianma | 10.1 | 1024×600 |
| TM101DDHG03 | Tianma | 10.1 | 1024×600 |
| TM101JDHP01 | Tianma | 10.1 | 1280×800 |
