| Nambari ya Sehemu | TV070WSM-NM0 |
| Chapa | BOE |
| Ukubwa | 7.0 |
| Maombi | Pad & Tablet |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | BOE |
| mfano wa paneli | TV070WSM-NM0 |
| saizi ya paneli | 7.0" |
| aina ya paneli | a-Si TFT-LCD, LCM |
| azimio | 1024(RGB)×600, WSVGA, 169PPI |
| muundo wa pixel | RGB Vertical Stripe |
| eneo la maonyesho | 153.6(W)×90(H) mm |
| ufunguzi wa bezel | - |
| saizi ya muhtasari | 161.16(W)×100.97(H) ×4.8(D) mm |
| uso | Glare (Haze 0%), Hard coating (3H) |
| mwangaza | 450 cd/m² (Typ.) |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| mwonekano bora zaidi | Symmetry |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| kuonyesha rangi | 16.7M 50% NTSC |
| aina ya taa | WLED , Without Driver |
| masafa | 60Hz |
| skrini ya kugusa | Without |
| uzito wa paneli | 90.0g (Max.) |
| maombi | Pad & Tablet |
| kiolesura cha ishara | MIPI (4 data lanes) , 40 pins Connector |
| voltage ya pembejeo | 1.8/3.3/9/19/-7V (Typ.)(VDD1/VDD3/AVDD/VGH/VGL) |
| mazingira | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 85 °C |
