| Nambari ya Sehemu | TV080WUM-AK2 |
| Chapa | BOE |
| Ukubwa | 8.0 |
| Maombi | Pad & Tablet |
| Azimio | 1200×1920 |
| Muundo | Assembly , a-Si TF |
| Mwangaza | |
| CR | 850:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 7S3P |
| Kiolesura | MIPI |
| mtengenezaji | BOE |
| jina la mfano | TV080WUM-AK2 |
| ukubwa wa skrini | 8.0 inch |
| aina ya skrini | Assembly , a-Si TFT-LCD |
| nambari ya pixel | 1200(RGB)×1920 (WUXGA) 283PPI |
| mpangilio | RGB Vertical Stripe |
| eneo amilifu(mm) | 107.64 × 172.224 (H×V) |
| muhtasari(mm) | 122.2 × 210.95 × 3.95 (H×V×D) |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 850 : 1 (Typ.) (TM) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| majibu | 25 (Typ.)(Tr+Td) ms |
| mtazamo mzuri | Symmetry |
| hali ya kazi | - |
| kina cha rangi | 16.7M 63% NTSC |
| backlight | 7S3P WLED , 15K hours , No Driver |
| wingi | 130g (Max.) |
| kutumika kwa | Pad & Tablet |
| kiwango cha upya | 60Hz |
| skrini ya kugusa | PCAP, Optical Bonding |
| aina ya ishara | MIPI (4 data lanes) , 39 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -20 ~ 60 °C Operating Temp.: -20 ~ 60 °C |
