| Nambari ya Sehemu | TV101WUB-NV0 |
| Chapa | BOE |
| Ukubwa | 10.1 |
| Maombi | Pad & Tablet |
| Azimio | 1200×1920 |
| Muundo | a-Si TFT-LCD, CELL |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No |
| Kiolesura | MIPI |
| chapa | BOE |
| mfano | TV101WUB-NV0 |
| ukubwa wa diagonal | 10.1 inch |
| aina | a-Si TFT-LCD, CELL |
| muundo wa pixel | 1200(RGB)×1920 [WUXGA] 225PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 135.36(H)×216.576(V) mm |
| muhtasari dim. | 140.26(H)×225.346(V) ×0.8(D) mm |
| mwangaza | 0 cd/m² |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| hali ya uendeshaji | ADS, Normally Black, Transmissive |
| unene wa sahani | 0.25+0.25 mm |
| uhamishaji | 5.1% (Typ.)(with Polarizer) |
| rangi ya msaada | 16.7M 71% NTSC |
| chanzo cha mwanga | No B/L |
| uzito | - |
| iliyoundwa kwa ajili ya | Pad & Tablet |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | Without |
| maelezo ya d-ic | COG Built-in 2 source chips |
| aina ya kiolesura | MIPI (4 data lanes) , 44 pins Connector |
| usambazaji wa nguvu | 3.3/9.8/4.8V (Typ.)(VDDI/AVDD/HAVDD) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
