| Nambari ya Sehemu | TV101WXM-NS0 |
| Chapa | BOE |
| Ukubwa | 10.1 |
| Maombi | Pad & Tablet |
| Azimio | 1280×800 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 900:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 6 |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| saizi ya paneli | 10.1" |
| azimio | 1280(RGB)×800, WXGA, 149PPI |
| eneo la maonyesho | 216.96(W)×135.6(H) mm |
| saizi ya muhtasari | 228.211(W)×148.86(H) ×4.59(D) mm |
| mwangaza | - |
| angle ya kutazama | 80/80/80/80 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 16.7M 50% NTSC |
| masafa | 60Hz |
| uzito wa paneli | 130g (Typ.) |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 45 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 80 °C |
| mfano wa paneli | TV101WXM-NS0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | - |
| uso | Hard coating (2H), Antireflection |
| uwiano wa utofautishaji | 900:1 (Typ.) (TM) |
| hali ya kuonyesha | ADS, Normally Black, Transmissive |
| wakati wa majibu | 30 (Typ.)(Tr+Td) |
| aina ya taa | 6 strings WLED , Without Driver |
| skrini ya kugusa | Without |
| maombi | Pad & Tablet |
