| Nambari ya Sehemu | TX18D210VM0BAA |
| Chapa | KOE |
| Ukubwa | 7.0 |
| Maombi | Industrial Outdoor H |
| Azimio | 800×480 |
| Muundo | LCM , LTPS TFT-LCD |
| Mwangaza | |
| CR | 1200:1 |
| Rangi | 262K |
| Mwangaza nyuma | WLED |
| Kiolesura | Parallel |
| mtengenezaji | KOE |
| ukubwa wa skrini | 7.0 inch |
| nambari ya pixel | 800(RGB)×480 (WVGA) 133PPI |
| eneo amilifu(mm) | 152.4 × 91.44 (H×V) |
| eneo la bezel(mm) | 156.2 × 94.5 (H×V) |
| mwangaza | 800 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mtazamo mzuri | Symmetry |
| kina cha rangi | 262K 72% NTSC |
| wingi | 214g (Typ.) |
| kiwango cha upya | 60Hz |
| aina ya ishara | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| usambazaji wa voltage | 3.3V (Typ.) |
| max. ukadiriaji | Storage Temp.: -40 ~ 90 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 5.0G (49.0 m/s²) |
| jina la mfano | TX18D210VM0BAA |
| aina ya skrini | LCM , LTPS TFT-LCD |
| mpangilio | RGB Vertical Stripe |
| muhtasari(mm) | 167.7 × 109.5 × 20.3 (H×V×D) |
| matibabu | - |
| uwiano wa utofautishaji | 1200 : 1 (Typ.) (TM) |
| majibu | 30 (Typ.)(Tr+Td) ms |
| hali ya kazi | IPS, Normally Black, Transmissive |
| backlight | WLED , 50K hours , With LED Driver |
| kutumika kwa | Industrial Outdoor High Brightness Automotive Display |
| skrini ya kugusa | Without |
| A070SN01 V3 | AUO | 7.0 | 800×600 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AT070TN92 V.X | Innolux | 7.0 | 800×480 |
| DLC0700YZG-1 | Other | 7.0 | 1024×600 |
| HE070IA-04R | Innolux | 7.0 | 800×1280 |
| HSD070PFW3-C01 | HannStar | 7.0 | 1024×600 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| M070SW46 R0 | IVO | 7.0 | 1200×1920 |
| PM070WU1 | E Ink | 7.0 | 800×480 |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
