| Nambari ya Sehemu | HE070IA-04R |
| Chapa | Innolux |
| Ukubwa | 7.0 |
| Maombi | PAD |
| Azimio | 800×1280 |
| Muundo | CELL |
| Mwangaza | 0 |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | No B/L |
| Kiolesura | LVDS |
| chapa ya paneli | CHIMEI INNOLUX |
| mfano wa paneli | HE070IA-04R |
| aina ya paneli | a-Si TFT-LCD , CELL |
| saizi ya paneli | 7.0 inch |
| azimio | 800(RGB)×1280 , WXGA |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| eneo la kazi | 94.2×150.72 mm |
| muhtasari | 101.5×159.52×1.27 mm |
| uso | Hard coating |
| kioo kina | 0.50+0.50 mm |
| uhamishaji | 3.6% (Typ.)(with Polarizer) |
| uwiano wa utofautishaji | 800:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193160% |
| wakati wa majibu | 50 (Typ.)(Tr+Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 40 pins |
| voltage ya pembejeo | 3.3/8.8/-7.0/22V (Typ.)(VDD/AVDD/VGH/VGL) |
| maombi | PAD |
