| Nambari ya Sehemu | YXD101301000-60 |
| Chapa | SEBO |
| Ukubwa | 10.1 |
| Maombi | CNS |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | 1000 |
| CR | 600:1 |
| Rangi | 16.2M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | SEBO |
| mfano wa paneli | YXD101301000-60 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 222.72×125.28 mm |
| muhtasari | 235×149.2×6.3 mm |
| uso | Antiglare |
| mwangaza | 1000 cd/m² (Typ.) |
| uwiano wa utofautishaji | 600:1 (Typ.) |
| kuonyesha rangi | 16.2M (6-bit + FRC), CIE193152% |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/60/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | WLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 8-bit), 60 pins |
| voltage ya pembejeo | 3.3/9.6/18/-6V (Typ.)(DVDD/AVDD/VGH/VGL) |
| maombi | CNS |
