| Nambari ya Sehemu | B101UAN07.0 |
| Chapa | AUO |
| Ukubwa | 10.1 |
| Maombi | PAD |
| Azimio | 1200×1920 |
| Muundo | LCM |
| Mwangaza | 400 |
| CR | 1000:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | MIPI |
| chapa ya paneli | AUO |
| mfano wa paneli | B101UAN07.0 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 10.1 inch |
| azimio | 1200(RGB)×1920 , WUXGA |
| hali ya kuonyesha | AHVA, Normally Black, Transmissive |
| eneo la kazi | 135.36×216.576 mm |
| muhtasari | 143×227.93×4.3 mm |
| uso | Glare (Haze 0%) |
| mwangaza | 400 cd/m² (Typ.) |
| uwiano wa utofautishaji | 1000:1 (Typ.) |
| kuonyesha rangi | 16.7M (8-bit), CIE193172% |
| wakati wa majibu | 25 (Typ.)(Tr+Tf) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 8S4PWLEDWithout Driver |
| kiolesura cha ishara | MIPI (4 data lanes), 45 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | PAD |
| B101UAN01.1 | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW0A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| B101UAN01.C | AUO | 10.1 | 1920×1200 |
| B101UAN01.E | AUO | 10.1 | 1920×1200 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| B101UAN07.2 | AUO | 10.1 | 1200×1920 |
| B101UAT02.1 | AUO | 10.1 | 1920×1200 |
| B080XAN02.0 | AUO | 7.9 | 768×1024 |
| B101EAN01.4 | AUO | 10.1 | 1280×800 |
| B116HAN03.1 | AUO | 11.6 | 1920×1080 |
| B116HAT03.1 | AUO | 11.6 | 1920×1080 |
| BP096WX1-100 | BOE | 9.6 | 800×1280 |
| CLAA101WJ01 | CPT | 10.1 | 1366×768 |
| LP079QX1-SP0V | LG Display | 7.9 | 1536×2048 |
| LTL101AL06-803 | Samsung | 10.1 | 1280×800 |
| P070ACB-DB1 | Innolux | 7.0 | 600×1024 |
| VVX11F009G00 | Panasonic | 11.6 | 1920×1080 |
