| Nambari ya Sehemu | A070FW05 V1 |
| Chapa | AUO |
| Ukubwa | 7.0 |
| Maombi | DPF |
| Azimio | 480×234 |
| Muundo | LCM |
| Mwangaza | 300 |
| CR | 300:1 |
| Rangi | |
| Mwangaza nyuma | WLED |
| Kiolesura | |
| chapa ya paneli | AUO |
| mfano wa paneli | A070FW05 V1 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 480(RGB)×234 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 154.08×86.58 mm |
| muhtasari | 166.2×101.2 mm |
| uso | |
| mwangaza | 300 cd/m² (Typ.) |
| uwiano wa utofautishaji | 300:1 (Typ.) |
| kuonyesha rangi | |
| wakati wa majibu | 12/18 (Typ.)(Tr/Td) |
| angle ya kutazama | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | WLED |
| rohs: | |
| maombi | DPF |
| A070FW01 | AUO | 7.0 | 480×234 |
| A070FW03 V1 | AUO | 7.0 | 480×234 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| A070FW03 V6 | AUO | 7.0 | 480×234 |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| A070FW03 VB | AUO | 7.0 | 480×234 |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| A070FW03 VB | AUO | 7.0 | 480×234 |
| A080SN01 V5 | AUO | 8.0 | 800×600 |
| AT070TN90 V.1 | Innolux | 7.0 | 800×480 |
| AT080TN52 | Innolux | 8.0 | 800×600 |
| DLC0800BIG-4 | Other | 8.0 | 800×600 |
| HSD101PFW3-D00 | HannStar | 10.1 | 1024×600 |
| LB070WV1-TD07 | LG Display | 7.0 | 800×480 |
| LW700AT9901 | Innolux | 7.0 | 800×480 |
| P64AN2AP08 | E Ink | 6.4 | 320×234 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
