| Nambari ya Sehemu | A070FW03 VB |
| Chapa | AUO |
| Ukubwa | 7.0 |
| Maombi | DPF |
| Azimio | 480×234 |
| Muundo | LCM |
| Mwangaza | 250 |
| CR | 400:1 |
| Rangi | Full color |
| Mwangaza nyuma | WLED |
| Kiolesura | Analog |
| chapa ya paneli | AUO |
| mfano wa paneli | A070FW03 VB |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 480(RGB)×234 |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 154.08×86.58 mm |
| muhtasari | 164.9×100 mm |
| uso | Antiglare, Hard coating (3H) |
| mwangaza | 250 cd/m² (Typ.) |
| uwiano wa utofautishaji | 400:1 (Typ.) |
| kuonyesha rangi | Full color , CIE193148% |
| wakati wa majibu | 4/12 (Typ.)(Tr/Td) |
| angle ya kutazama | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| aina ya taa | 3S6PWLEDWithout Driver |
| kiolesura cha ishara | TFT Specific Analog RGB, 26 pins |
| voltage ya pembejeo | 3.3/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| maombi | DPF |
