| Nambari ya Sehemu | AM-1024600DTZQW-TA6H |
| Chapa | AMPIRE |
| Ukubwa | 7.0 |
| Maombi | Industrial Outdoor H |
| Azimio | 1024×600 |
| Muundo | a-Si TFT-LCD, LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa | AMPIRE |
| mfano | AM-1024600DTZQW-TA6H |
| ukubwa wa diagonal | 7.0 inch |
| aina | a-Si TFT-LCD, LCM |
| muundo wa pixel | 1024(RGB)×600 [WSVGA] 170PPI |
| usanidi | RGB Vertical Stripe |
| eneo la kazi | 154.221(H)×85.92(V) mm |
| muhtasari dim. | 164.9(H)×128(V) ×12.6(D) mm |
| mwangaza | 850 cd/m² (Typ.) |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| tazama mwelekeo | Symmetry |
| wakati wa majibu | 13/15 (Typ.)(Tr/Td) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| hali ya uendeshaji | IPS, Normally Black, Transmissive |
| rangi ya msaada | 16.7M 58% NTSC |
| chanzo cha mwanga | WLED , 50K hours , With LED Driver |
| uzito | - |
| iliyoundwa kwa ajili ya | Industrial Outdoor High Brightness |
| kiwango cha fremu | 60Hz |
| jopo la kugusa | PCAP |
| aina ya kiolesura | LVDS (1 ch, 8-bit) , 20 pins Connector |
| usambazaji wa nguvu | 3.3V (Typ.) |
| mazingira | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
