| Nambari ya Sehemu | BA070WS1-400 |
| Chapa | BOE |
| Ukubwa | 7.0 |
| Maombi | MP4 |
| Azimio | 1024×600 |
| Muundo | LCM |
| Mwangaza | 350 |
| CR | 700:1 |
| Rangi | 262K/16.7M |
| Mwangaza nyuma | WLED |
| Kiolesura | LVDS |
| chapa ya paneli | BOE |
| mfano wa paneli | BA070WS1-400 |
| aina ya paneli | a-Si TFT-LCD , LCM |
| saizi ya paneli | 7.0 inch |
| azimio | 1024(RGB)×600 , WSVGA |
| hali ya kuonyesha | TN, Normally White, Transmissive |
| eneo la kazi | 153.6×90 mm |
| muhtasari | 167.25×104.65×3 mm |
| uso | Clear, Hard coating |
| mwangaza | 350 cd/m² (Typ.) |
| uwiano wa utofautishaji | 700:1 (Typ.) |
| kuonyesha rangi | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193150% |
| wakati wa majibu | 20 (Typ.)(Tr+Td) |
| angle ya kutazama | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| masafa | 60Hz |
| aina ya taa | 3S6PWLEDWithout Driver |
| kiolesura cha ishara | LVDS (1 ch, 6/8-bit), 39 pins |
| voltage ya pembejeo | 3.3V (Typ.) |
| maombi | MP4 |
| BA070WS1-100 | BOE | 7.0 | 1024×600 |
| BA070WS1-200 | BOE | 7.0 | 1024×600 |
| BA070WS1-300 | BOE | 7.0 | 1024×600 |
| BA070WS1-400 | BOE | 7.0 | 1024×600 |
| BA070WS1-401 | BOE | 7.0 | 1024×600 |
| BA070WS1-402 | BOE | 7.0 | 1024×600 |
| CLAA070NC0DCW | CPT | 7.0 | 1024×600 |
| DLC0700DDG-4 | Other | 7.0 | 800×480 |
| LPM070W425D | JDI | 7.0 | 1200×1920 |
| LTA070B2C0F | TOSHIBA | 7.0 |
| A070VW04 V4 | AUO | 7.0 | 800×480 |
| AT070TN83 V.3 | Innolux | 7.0 | 800×480 |
| BA070WS1-100 | BOE | 7.0 | 1024×600 |
| CLAA070ND22CW | CPT | 7.0 | 1024×600 |
| CLAA070ND23CW | CPT | 7.0 | 1024×600 |
| CLAA070NP01HXG | CPT | 7.0 | 1024×600 |
| DLC0700JMG-6 | Other | 7.0 | 1024×600 |
| EJ070NA-01J | Innolux | 7.0 | 1024×600 |
| HV070WS1-1E1 | HYDIS | 7.0 | 1024×600 |
| LB070WV6-TD06 | LG Display | 7.0 | 800×480 |
