| Nambari ya Sehemu | AM-1280800NGTZQW-17H |
| Chapa | AMPIRE |
| Ukubwa | 10.1 |
| Maombi | Industrial Outdoor H |
| Azimio | 1280×800 |
| Muundo | a-Si TFT-LCD , LCM |
| Mwangaza | |
| CR | 800:1 |
| Rangi | 16.7M |
| Mwangaza nyuma | 7S6P |
| Kiolesura | LVDS |
| chapa ya paneli | AMPIRE |
| saizi ya paneli | 10.1" |
| azimio | 1280(RGB)×800, WXGA, 149PPI |
| eneo la maonyesho | 216.96(W)×135.6(H) mm |
| saizi ya muhtasari | 231(W)×154.4(H) ×6.2(D) mm |
| mwangaza | 1500 cd/m² (Typ.) |
| angle ya kutazama | 85/85/85/85 (Typ.)(CR≥10) |
| mwonekano bora zaidi | Symmetry |
| kuonyesha rangi | 16.7M 45% NTSC |
| masafa | 60Hz |
| uzito wa paneli | TBD |
| kiolesura cha ishara | LVDS (1 ch, 8-bit) , 40 pins Connector |
| voltage ya pembejeo | 3.3V (Typ.) |
| mazingira | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -30 ~ 80 °C |
| mfano wa paneli | AM-1280800NGTZQW-17H |
| aina ya paneli | a-Si TFT-LCD , LCM |
| muundo wa pixel | RGB Vertical Stripe |
| ufunguzi wa bezel | 220.76(W)×140.4(H) mm |
| uso | Hard coating |
| uwiano wa utofautishaji | 800:1 (Typ.) (TM) |
| hali ya kuonyesha | IPS, Normally Black, Transmissive |
| wakati wa majibu | 25 (Typ.)(Tr+Td) |
| aina ya taa | 7S6P WLED , 50K hours , Without Driver |
| skrini ya kugusa | Without |
| maombi | Industrial Outdoor High Brightness |
